Invisible Fiber

Invisible Fiber

Overview:

Invisible optical cable is the abbreviation for transparent tight-buffered optical cable covered with hot melt glue. It is an optical cable composed of G.657.B3 or G657A optical fiber, a transparent tight jacket layer. Each layer is extruded step by step using an extrusion process. The application of invisible optical cable is where the user does not accept the use of leather fiber optic cable to enter the home or solves the problem of the user's difficulty in entering the home, especially in the old residential area and office. The fiber has a minimum bending radius. When laying, there is no need to nail, make brackets, perforate, pipes, etc., to destroy the original indoor structure, or because of the discontinuity of the laying, the optical cable will sag and fall off and other safety hazards. At the same time, the optical cable is almost transparent so it will not affect the indoor decoration, simple construction method, only need hand-held heating installation tools to complete the laying project.

Product Description:

Features:

  • It is convenient and fast to take out rubber fiber satthe sametime,which is more beautiful,more convenient and more efficient wiring experience.
  • 360°adjustable glue gun nozzle,horizontal and vertical,flexible switching, effectively solvingthe problems of included angles,dead corners and corners during the wiring process.
  • Adjust the temperature according to your own usage conditions and quickly dispenseglue,suitable for continuousoperation.
  • Concealed install,easy to install,economical saving,smallsize, light weight, small bendin gradius.

Application:

  • FTTR Indoorcabling.
  • Broad band installation.
  • Use din patch cord and pigtails

Product Characteristics:

Parameter G657A2 G657B3 50/125μm 62.5/125μm
Attenuation @850nm ≤3.0dB/km ≤3.0dB/km - -
Attenuation @1300nm ≤1.0dB/km ≤1.0dB/km - -
Attenuation @1310nm ≤0.35dB/km ≤0.40dB/km - -
Attenuation @1550nm ≤0.21dB/km ≤0.23dB/km - -
Bandwidth @850nm ≥500MHz·km ≥200MHz·km - -
Bandwidth @1300nm ≥1000MHz·km ≥600MHz·km - -
Numerical Aperture 0.200±0.015NA 0.275±0.015NA - -
Cable Cut-off Wavelength ≤1260nm ≤1480nm - -
