DWDM MUX AND DEMUX (Red 21-32) & (Blue 42-45/49-56)1U RACK WITH 1 LGX BOX 12CH BIDI SINGLE FIBER (SIDE B) 41

Discover our latest products and services

DWDM MUX AND DEMUX (Red 21-32) & (Blue 42-45/49-56)1U RACK WITH 1 LGX BOX 12CH BIDI SINGLE FIBER (SIDE B) 41

Rs 78408.00

(3 Reviews)
Product Info
  • Unit: pc(1)
  • Product ID: 1489

Product Specification:

WavelengthC21-C28/C42-C45&C50-C56Channel Spacing100GHz (0.8nm)
Channel Passband±0.11nmTechnologyTFF (Thin Film Filter)
Insertion Loss≤3.8dBCenter Wavelength Accuracy±0.05nm
Return Loss≥ 45dBDirectivity≥ 45dB

Polarization Mode

Dispersion

≤ 0.1ps

Polarization

Dependent Loss

≤ 0.3dB
Channel Isolation

Adjacent ≥30dB

Non-adjacent ≥ 45dB

Temperature

Operating -20 to70°C

Storage   -40 to 85°C

Net Weight3.5KGDimensions (HxWxD)44*440*230mm

Video : DWDM MUX AND DEMUX (Red 21-32) & (Blue 42-45/49-56)1U RACK WITH 1 LGX BOX 12CH BIDI SINGLE FIBER (SIDE B)

Product Specifications
  • Warranty: 53-TRIAL-1 Year 32
  • Country of Origin: 247-TRIAL-China 180
  • Delivery Time (if import required): 126-TRIAL-CH-NP 15-20Days 178

Product Specification:

WavelengthC21-C28/C42-C45&C50-C56Channel Spacing100GHz (0.8nm)
Channel Passband±0.11nmTechnologyTFF (Thin Film Filter)
Insertion Loss≤3.8dBCenter Wavelength Accuracy±0.05nm
Return Loss≥ 45dBDirectivity≥ 45dB

Polarization Mode

Dispersion

≤ 0.1ps

Polarization

Dependent Loss

≤ 0.3dB
Channel Isolation

Adjacent ≥30dB

Non-adjacent ≥ 45dB

Temperature

Operating -20 to70°C

Storage   -40 to 85°C

Net Weight3.5KGDimensions (HxWxD)44*440*230mm

Video : DWDM MUX AND DEMUX (Red 21-32) & (Blue 42-45/49-56)1U RACK WITH 1 LGX BOX 12CH BIDI SINGLE FIBER (SIDE B)

Additional Specifications
Base Unit pc(1)
Category OFC Passive Devices
SKU
Product Code 211
Trackable Yes
Taxable Yes
