ADSS Suspension Clamp Span 100M 143

Discover our latest products and services

ADSS Suspension Clamp Span 100M 143

Rs 0.00

(3 Reviews)
Product Info
  • Unit: pc(1)
  • Product ID: 686

Suspensions set for 100m span

Description:
The ADSS suspension clamp is used to connect the ADSS cables on the straight pole/towers. They feature in sample structures, easy installation and lower cost.


1. Configuration:

S.NO

Description

Code

Material

Qty

Weight(kg)

1

U clevis

U-5

Forged steel

1

0.3

2

Housing

Aluminum alloy,length:1 00mm

1

0.4

3

Synthetic rubber length:120m m

1

0.15

Total weight(kg)

0.85



Type 1:

1- Anchor shackle: forged steel 2- Housing: aluminum alloy
3- Rubber insert: synthetic rubber 4- Bolt, nut, cotter pin

Type 2:

1- Stainless steel band (1.2m)
2- Stainless steel base: 1pcs
3- Rubber insert : synthetic rubber
4- Housing: aluminum alloy
5- Bolt, nut, washer, spring washer: 1set

2. Features:

Simple structures, easy installation, and lower cost.

Applications: Poles/towers with span of less than 100m, and line angle of less

than 15°

4. Technical Data:

RTS: greater than 20kN recommended span length: 100m

SN

Cable Diameter (mm)

Armor Rods (mm)

Anchor Shackle

1

9.0-12

0

U-5

2

12-14

0

U-5

3

14-16

0

U-5

4

16-18

0

U-5


Suspensions set for 100m span

Description:
The ADSS suspension clamp is used to connect the ADSS cables on the straight pole/towers. They feature in sample structures, easy installation and lower cost.


1. Configuration:

S.NO

Description

Code

Material

Qty

Weight(kg)

1

U clevis

U-5

Forged steel

1

0.3

2

Housing

Aluminum alloy,length:1 00mm

1

0.4

3

Synthetic rubber length:120m m

1

0.15

Total weight(kg)

0.85



Type 1:

1- Anchor shackle: forged steel 2- Housing: aluminum alloy
3- Rubber insert: synthetic rubber 4- Bolt, nut, cotter pin

Type 2:

1- Stainless steel band (1.2m)
2- Stainless steel base: 1pcs
3- Rubber insert : synthetic rubber
4- Housing: aluminum alloy
5- Bolt, nut, washer, spring washer: 1set

2. Features:

Simple structures, easy installation, and lower cost.

Applications: Poles/towers with span of less than 100m, and line angle of less

than 15°

4. Technical Data:

RTS: greater than 20kN recommended span length: 100m

SN

Cable Diameter (mm)

Armor Rods (mm)

Anchor Shackle

1

9.0-12

0

U-5

2

12-14

0

U-5

3

14-16

0

U-5

4

16-18

0

U-5


Additional Specifications
Base Unit pc(1)
Category OFC TELECOM GOODS
SKU
Product Code 34
Trackable Yes
Taxable Yes
