Fusion Splicer Comway C10S v2 40

Category

Specification

Model

Comway C10S V2

Type

Core Alignment Fusion Splicer

Application

SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZ/NZDS (ITU-T G.655), BI (ITU-T G.654), EB (ITU-T G.654)

Splice Method

Core alignment with 6 motors

Splice Loss

0.02dB (SM), 0.01dB (MM), 0.04dB (DS/NZDS)

Return Loss

>60dB

Protection Sleeve Length

10mm - 60mm

Splicing Time

~5 seconds (SM FAST mode)

Heating Time

~8 seconds

Splice Cycle per Battery Charge

>300 cycles

Magnification

750X single-axis view

Display

High-resolution LCD touchscreen, visible under sunlight

Shock Resistance

Withstands drop from 76cm on 5 sides

Waterproof

IP52 rated

Dustproof

IP5X rated

Wind Resistance

Up to 15m/s

Operating Temperature

-10°C to +50°C

Storage Temperature

-40°C to +80°C

Humidity

0-95% RH (non-condensing)

Power Supply

AC 100-240V, 50/60Hz; DC 12V input

Battery Capacity

7800mAh lithium-ion, rechargeable

Charging Time

~3 hours

Fiber Cleaver

High-precision fiber cleaver included

Stripping

Suitable for 250μm and 900μm coated fibers

Auto Fiber Identification

YES

Splice Programs

Multiple pre-installed and customizable programs

Remote Locking

Anti-theft protection with remote access

GPS Function

Optional GPS module available

Language Support

Multiple languages supported

Interface

USB and HDMI for data transfer and software updates
