The DK-MC1035 series media converter, Single Fiber 10/100/1000 20 KM, adopts a store and forward, no fan, low power consumption design with the advantages of convenient use, small size, and simple maintenance. Product design-20°C ~ +70°C wide range of operating temperature, stable and reliable performance, can be widely used in a variety of broadband data transmission fields.
Experience enhanced network management capabilities with features like broadcast filtering, address auto-learning, automatic updates, and store-and-forward operation, ensuring seamless data transmission with minimal latency.
With a 512KB cache and a MAC address table of 4KB, our converter delivers lightning-fast data processing while supporting a wide range of Ethernet standards, including 10Base-Tx to 10Base-Fx, 100Base-Tx to 100Base-Fx, and 1000Base-Tx to 1000Base-Fx fiber media conversion.
Compliant with IEEE standards such as 802.3, 802.3U, 802.1X, 802.3Z/AB, and 802.1d, our converter ensures compatibility and interoperability across diverse network environments.
Parameter | Details |
---|---|
Provider Mode | Ports |
Fixed Port | 1 * 1000Base-X, 1 * 10/100/1000Base-T |
Power Interface | DC Port |
LED Indicators | PWR, Link/ACT LED |
Cable Type & Transmission Distance | Twisted-pair: 0-100m (CAT5e, CAT6) |
Monomode Optical Fiber: 3KM/20KM/40KM/60KM/80KM/100KM/120KM | |
Electrical Specifications | |
Input Voltage | DC 5V |
Total Power Consumption | Total Power: < 4W |
Environment | |
Operating Temperature | -20°C ~ +70°C |
Storage Temperature | -20°C ~ +70°C |
Relative Humidity | 5% ~ 95% non-condensing |
Thermal Methods | Fanless design, natural heat dissipation |
MTBF | 100,000 hours |
Mechanical Dimensions | |
Product Size | 93 x 71 x 27mm |
Installation Method | Desktop |
Weight | 0.17KG * 2 |
Certification | |
Certification | CE/FCC/RoHS |
Accessories | |
Accessories | Device, manual, power adapter (EU/US/UK/AU plug optional) |
Media Converter 10/100/1000M 3km 1Fiber 1RJ45 SM single fiber SC (A)
Media Converter 10/100/1000M 3km 1Fiber 4RJ45 SM single fiber SC (B)
The DK-MC1035 series media converter, Single Fiber 10/100/1000 20 KM, adopts a store and forward, no fan, low power consumption design with the advantages of convenient use, small size, and simple maintenance. Product design-20°C ~ +70°C wide range of operating temperature, stable and reliable performance, can be widely used in a variety of broadband data transmission fields.
Experience enhanced network management capabilities with features like broadcast filtering, address auto-learning, automatic updates, and store-and-forward operation, ensuring seamless data transmission with minimal latency.
With a 512KB cache and a MAC address table of 4KB, our converter delivers lightning-fast data processing while supporting a wide range of Ethernet standards, including 10Base-Tx to 10Base-Fx, 100Base-Tx to 100Base-Fx, and 1000Base-Tx to 1000Base-Fx fiber media conversion.
Compliant with IEEE standards such as 802.3, 802.3U, 802.1X, 802.3Z/AB, and 802.1d, our converter ensures compatibility and interoperability across diverse network environments.
Parameter | Details |
---|---|
Provider Mode | Ports |
Fixed Port | 1 * 1000Base-X, 1 * 10/100/1000Base-T |
Power Interface | DC Port |
LED Indicators | PWR, Link/ACT LED |
Cable Type & Transmission Distance | Twisted-pair: 0-100m (CAT5e, CAT6) |
Monomode Optical Fiber: 3KM/20KM/40KM/60KM/80KM/100KM/120KM | |
Electrical Specifications | |
Input Voltage | DC 5V |
Total Power Consumption | Total Power: < 4W |
Environment | |
Operating Temperature | -20°C ~ +70°C |
Storage Temperature | -20°C ~ +70°C |
Relative Humidity | 5% ~ 95% non-condensing |
Thermal Methods | Fanless design, natural heat dissipation |
MTBF | 100,000 hours |
Mechanical Dimensions | |
Product Size | 93 x 71 x 27mm |
Installation Method | Desktop |
Weight | 0.17KG * 2 |
Certification | |
Certification | CE/FCC/RoHS |
Accessories | |
Accessories | Device, manual, power adapter (EU/US/UK/AU plug optional) |
Media Converter 10/100/1000M 3km 1Fiber 1RJ45 SM single fiber SC (A)
Media Converter 10/100/1000M 3km 1Fiber 4RJ45 SM single fiber SC (B)
Base Unit | Pair(2pcs) |
---|---|
Category | OFC Active Devices |
SKU | |
Product Code | 205 |
Trackable | Yes |
Taxable | Yes |
