1G-2SC-4POE+1uplink
is a non-network management type independently developed by our company and provides 4 10/100/1000Mbps adaptive RJ45 port and 2 SC ports. Each RJ45 port supports MDI/MDIX automatic rollover and wire speed forwarding functions. Where 1-4 ports have PoE function, support IEEE802.3af/IEEE802.3at standard, can be used as Ethernet power supply equipment, can automatically detect and identify the standard receiving equipment, and power it through the network cable.
Easy to use, no configuration, plug and play, flexible expansion of home, office network without power line layout restrictions, power can be freely selected.
Product Description :
l 4 ports Mbps RJ45 10/100/1000 2SC
l 4 PoE power ports (Port1~4)
l Compatible with 802.3 af/at standards;
l Output power up to 30 W per PoE port
l Automatic detection of PD equipment
l PoE overload warning light
l Support IEEE802.3x full duplex flow control and Backpressure half duplex flow control;
l Monitor working status of panel indicator light and help fault analysis
l Support IEEE802.3az Energy Efficiency
Product Specifications
Product Name | 4 GE 2 SC Full Gigabit PoE Switch |
Model | 1G-2SC-4POE+1uplink |
PORTS | 4*10/100/1000Mbps 2SC 1000Mbps |
Standards | IEEE802.3,IEEE802.3u,IEEE802.3ab,IEEE802.3az,IEEE802.3x,IEEE802.3af,IEEE802.3at |
Network media (cable) | 10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or later UTP(≤100 meter) 1000BASE-TX: Cat6 or later UTP(≤100 meter) |
MAC Address Sheet | 1K, automatic learning, automatic updating |
Transmission mode | Storage forwarding |
Backplane bandwidth | 12G |
Power input | DC12V-52V |
Power supply | External power supply 56W MAX72 W |
PoE port | Port1~4 |
RJ45PoE power supply | Mode A positive 1/2 negative 3/6 (Custom power supply mode 4 / 5 V + 7 / 8 V-) |
PoE port output | 30W( largest) |
Working temperature | 0°C ~40°C |
Storage temperature | -40°C ~70°C |
Working humidity | 10%~90% without condensation |
Storage humidity | 5%~90% without condensation |
Appearance Size (L*W*H) | 149*94*28mm |
Machine weight | Product weight(0.32Kg) , Packing weight (0.56Kg) |
Package specification | 30SET W*D*H 435*345*195 17.5Kg |
authentication | CE FCC |
Product Application:
The switch is widely used in conference room system, education system, security system, industrial computer, robot, gateway and so on.
1G-2SC-4POE+1uplink
is a non-network management type independently developed by our company and provides 4 10/100/1000Mbps adaptive RJ45 port and 2 SC ports. Each RJ45 port supports MDI/MDIX automatic rollover and wire speed forwarding functions. Where 1-4 ports have PoE function, support IEEE802.3af/IEEE802.3at standard, can be used as Ethernet power supply equipment, can automatically detect and identify the standard receiving equipment, and power it through the network cable.
Easy to use, no configuration, plug and play, flexible expansion of home, office network without power line layout restrictions, power can be freely selected.
Product Description :
l 4 ports Mbps RJ45 10/100/1000 2SC
l 4 PoE power ports (Port1~4)
l Compatible with 802.3 af/at standards;
l Output power up to 30 W per PoE port
l Automatic detection of PD equipment
l PoE overload warning light
l Support IEEE802.3x full duplex flow control and Backpressure half duplex flow control;
l Monitor working status of panel indicator light and help fault analysis
l Support IEEE802.3az Energy Efficiency
Product Specifications
Product Name | 4 GE 2 SC Full Gigabit PoE Switch |
Model | 1G-2SC-4POE+1uplink |
PORTS | 4*10/100/1000Mbps 2SC 1000Mbps |
Standards | IEEE802.3,IEEE802.3u,IEEE802.3ab,IEEE802.3az,IEEE802.3x,IEEE802.3af,IEEE802.3at |
Network media (cable) | 10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or later UTP(≤100 meter) 1000BASE-TX: Cat6 or later UTP(≤100 meter) |
MAC Address Sheet | 1K, automatic learning, automatic updating |
Transmission mode | Storage forwarding |
Backplane bandwidth | 12G |
Power input | DC12V-52V |
Power supply | External power supply 56W MAX72 W |
PoE port | Port1~4 |
RJ45PoE power supply | Mode A positive 1/2 negative 3/6 (Custom power supply mode 4 / 5 V + 7 / 8 V-) |
PoE port output | 30W( largest) |
Working temperature | 0°C ~40°C |
Storage temperature | -40°C ~70°C |
Working humidity | 10%~90% without condensation |
Storage humidity | 5%~90% without condensation |
Appearance Size (L*W*H) | 149*94*28mm |
Machine weight | Product weight(0.32Kg) , Packing weight (0.56Kg) |
Package specification | 30SET W*D*H 435*345*195 17.5Kg |
authentication | CE FCC |
Product Application:
The switch is widely used in conference room system, education system, security system, industrial computer, robot, gateway and so on.
