Product Description:

HSGQ-843 is one of the latest 84 series of industrial grade XPON passive optical network communication terminals launched by our company. The product provides 4 Ge and 1 optical fiber access port and metal shell; The stability and wide compatibility of the product are suitable for high-speed interconnection projects such as smart city and smart transportation. It can work normally under the harsh environment of high and low temperature difference, and well meet the application of high-speed data transmission.Industrial applications, the operating environment supports the temperature difference between -40°C~+75°C, and all ports support 6KV lightning protection function, which is safe regardless of indoor and outdoor deployment.

Technical Parameter:

Module	Parameter
User Interface	54V POE input power supply
	RJ45 lightning protection: CM 6KV, DM 2KV
	1x XPON adaptive interface
	Interface type: px20+
	Uplink and downlink speed: 1.25Gbps/2.5Gbps
PON Interface	Transmitted optical power: 0~4dBm
	Optical receive power: 7--27dBm
	Sensitivity: -28dBm
	Uplink and downlink wavelength: 1310nm/1490nm
	Power supply line sequence 1/2(+), 3/6(-)
PoE/POE+	POE input voltage: 54V DC
	Maximum power of a single port: 30W
	Maximum power of the whole machine: 60W
Management Configuration	Support web interface management
	Support telnet command remote login management
Size	145mm (L) x 105mm (W) x 25mm (H)
Environmental	Working environment: -40°C~80°C: 10%~85%
	Storage environment: -40°C~80℃: 5%~95%
Power Supply	110-240AC

Key Features:

The point to multipoint network topology is adopted to effectively collect and aggregate the scattered Ethernet services of users, and the standard RJ45 Fast Ethernet interface is provided on the user side.
Dynamic bandwidth allocation mechanism enables all users to share bandwidth more reasonably, realize reliable quality of service (QoS), and ensure theservice quality of different services in the same network.

Support IGMP multicast and make effective use of broadband

Support multicast VLAN

GPON is adopted to meet ITU-T G.984/G.988 standards

Provide remote management through OLT and support local console management

Support the line loopback detection function of user side Ethernet interface

Support IEEE802.1q VLAN protocot

Support broadcast storm suppression

Support IEEE802.3x flow control (full duplex)

Support IEEE802.1p, cos protocol

Support WR and SP queue scheduling algorithms

Support port speed limit

Support-40°C~+75°C high and low temperature difference
