G01 is a small-capacity cassette GPON OLT, meeting the requirements of ITU-T G.984/G.988 and the relative standards of China Telecom/Unicom GPON, with super GPON access capacity, carrier-class reliability, and a complete security function. It can satisfy long-distance optical fiber access requirements on account of its excellent management, maintenance, and monitoring capabilities, abundant service features, and flexible network mode. G01 can be used with network management systems so as to provide users with comprehensive access and a perfect solution.
G01 provides a 1x downlink GPON port, 4xGE RJ45 port, and 1×10G SFP+ port. The height is only 1U for easy installation and space-saving. G01 is suitable for Broadcast three-in-one, video surveillance network, enterprise LAN, Internet of Things, etc.
Category |
Description |
Product Specifications |
|
Interface |
1 x GPON |
4 x GE RJ45 |
|
1: 10G SFP+ |
|
ITUT G.984x3988 |
|
Password Authentication Modes |
Terminal access |
Password authentication |
|
Distance |
Up to 60km on a single fiber |
Split Ratio |
1:128 split ratio on single PON port |
DBA Algorithm |
Particle for 64 Kbit/s |
Management Functions |
Standard OMCI management function |
ONU batch software upgrade |
|
PON port optical parameter detection |
|
Auto registration ONU bound with default profile |
|
Memory |
128MB |
Flash |
512MB |
DDR Size |
166mm x 157mm x 39mm |
Weight |
<5kg |
Management Ports |
Console port |
Environment |
Operating Temperature: -10°C - 55°C |
Storage Temperature: -40°C ~ 70°C |
|
Storage Humidity: 5%–95% (non-condensing) |
|
Power Supply |
DC 12V |
Power Consumption |
|
Platform Management Features |
|
Version Release |
Configuration and Management |
Status |
|
License Management |
|
Permission Management |
|
User Management |
|
CLI, WEB, SNMP, NMS, and CLOUD |
|
Software and Bootrom Upgrade by TFTP and FTP |
|
Chinese-English Command Prompt |
|
Ping and Debug Diagnosis |
|
UserLog/Alarm Management |
|
PON Features |
|
PON Status |
Uplink Status |
Performance Monitor |
System Monitor |
Key Features |
|
MAC Address Table |
16K MAC address table |
DBA |
Flexible DBA for up-and-down traffic speed control |
Traffic Control |
Port-based traffic control |
Traffic shaping |
|
ONL Identification |
Automatic identification, auto-discovery, and auto-registration |
VLAN Support |
Multicast support, IGMP snooping |
Cloud Management |
|
Product Advantages |
|
Uplink Flexibility |
Support for electrical and optical modules; flexible configuration according to networking needs |
Optical Link Diagnosis |
Warning mechanism for optical links |
High Reliability |
Dual power supply support |
Dimension |
TU cassette design saves space and has low power consumption |
Capacity |
Each PON supports up to 128 terminals; the whole device supports up to 128 ONUs under full configuration |
Ordering Information |
|
Product Model |
HSGQ-G01 |
Description |
1-GPON Part |
6-GE RJ45 |
|
1-10G SFP+ |
