HSGQ XPON STICK

Overview of HSGQ-XPON-STICK:

HSGQ-XPON-STICK is a miniature XPON SFP ONU device that can be plugged into the SFP optical port of a switch or routing device to provide XPON network access to the device. In principle, the HSGQ-XPON-STICK is an optical module, but it has a built-in CPU, flash memory, and a system, so it can be used as an optical cat.

Product Description for  HSGQ-XPON-STICK

Key Features of HSGQ-XPON-STICK:

  • 1490 nm wavelength downstream, 1310 nm wavelength upstream
  • GPON: 2.5 GB/s line rate downstream, 1.25 Gb/s line rate upstream
  • EPON: 1.25 GB/s line rate downstream, 1.25 Gb/s line rate upstream
  • Complies with SFP Multi-Source Agreement (MSA) SFF-80741
  • Digital Diagnostic Monitor (DDM) interface compatible with SFF-8472
  • It complies with ITU-T G.984.2, G.984.2 Amendment 1
  • Complies with ITU-T G.988 ONU management and control interface (OMCI)
  • Class I laser safety standard IEC-60825 compliant
  • RoHS compliance

Technical Parameters of HSGQ-XPON-STICK:

Module Parameter
User Interface
POUND 1* POUND
POUNDS
Physical Interface: PON Port
Size 8.2mm x 6.8mm x 75mm
Type SC
Weight <19g
Environment
Operating Temperature (I Temp) -40°C ~ 85°C
Operating Temperature (C Temp) 0°C ~ 70°C
Storage Humidity 5% ~ 95% (non-condensing)
Power Supply 3.3V
Power Consumption <2.5W
PON Function GPON/EPON adaptive
SFU Mode Optionally support some functions of HGU (DHCP/PPPoE/NAT)
Configure MAC Address Support
Configure SN Support
Configure Vendor ID Support
Configure PVID Support
DDMI Support
Management Http/telnet/SSH/TR069
SFP MSA Standard Support
VLAN Transport Transmission
VLAN VLAN switch function

Advantages of HSGQ-XPON-STICK:

  • Small Form-Factor Pluggable (SFP)
  • Easy to install
  • Low power consumption
