Media Converter 10/100/1000M 1Fiber 4RJ45 SM single fiber SC (B) 3km

Media Converter 10/100/1000M 3km 1Fiber 4RJ45 SM single fiber SC (B)

Media Converter  Overview:

The non-managed media converters, which give you economic solutions for media conversion between fiber and copper Ethernet. It provides you SC,FC or ST connectors for your fiber optic cables and RJ45 for twisted pair UTP cable connection.The maximum extension is up to 120km over fiber.this media conveter are available in pair so that if your requirement are for pair of the media converter then you can contact us at eman communications.

Media Converter 10/100/1000M 3km 1Fiber 4RJ45 SM single fiber SC (B) Description:

Features for Media Converter 10/100/1000M 3km 1Fiber 4RJ45 SM single fiber SC (B):

* In conformity to IEEE802.3 10base-T, IEEE802.3u 100 base-TX/FX, IEEE802.3ab 1000 base-T, IEEE802.3z,1000base-SX/LX, IEEE802.1a, IEEE802.1PQ0S, IEEE802.1d Spanning Tree.

* Hot Plug-gable & Wall-Mountable.
* Stable performance more than 50thousand hours with fault-free.

* Unique IC solution applied.
* Supports 10/100Mbps and 10/100/1000M full/half duplex, easy upgrades.
* Auto MDI/MDI-X.

* Auto Negotiation.

* Support flow control.
* Stable performance more than 50 thousands hours with fault-free.
* In conformity with safety code of FCC, CE and RoHS.

Specifications of Media Converter 10/100/1000M 3km 1Fiber 4RJ45 SM single fiber SC (B):

Optical Interface

Connector

1x9 SC/FC/ST

Data Rate

1000Mbps

Duplex Mode

Full duplex

Fiber

SM 9/125um

Distance

10/100/1000Mbps:

SM /3km

Wavelength

SM 1310nm/1550nm

UTP Interface

Connector

RJ45

Data Rate

10/100/1000Mbps

Duplex Mode

Half/full duplex

Cable

Cat5,Cat6

Power Input

Adapter Type

DC5V

Power Consumption

<5W

Port Numbers

4* 10/100/1000 RJ45 + 1* 1.25G SC fiber

Weight

Adapter Type

0.4kg

Dimensions

Adapter Type

95mm*70mm*25mm

Temperature

0~50℃ Operating; -40~70℃ Storage

Humidity

5~95%(no condensing)

MTBF

≥10.0000h

Certification

CE,FCC,RoHS



Application for Media Converter 10/100/1000M 3km 1Fiber 4RJ45 SM single fiber SC (B):

* Extend your Ethernet connection up to 0~120km away using fiber optics

* Creates an economical Ethernet-fiber/copper-fiber link for connecting remote sub-networks to larger fiber optic networks/backbones

* Converts Ethernet to fiber, fiber to copper/Ethernet, ensuring optimum network scalability for connecting two or more Ethernet network nodes (e.g. connecting two buildings on the same campus)

* Designed to provide high-speed bandwidth for demanding large scale work groups that require expansion of Gigabit Ethernet Network

You can check the brief product description from various sources for more details.
