DWDM SFP 10G 80KM SM LC, DDM - CH 47

SFP-DWxxTG-80DC

10.3Gbps SFP+ DWDM Transceiver, Single Mode, 80km Reach

Product Features

•   Supports up to 10.7Gbps bit rates

•   Hot-pluggable SFP+ footprint

•   100GHz ITU, C Band DWDM Cooled EML laser and APD photodiode, Up to 80km for SMF transmission

•   Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle

•   Compatible with RoHS

•   Single +3.3V power supply

•   Real Time Digital Diagnostic Monitoring

•   Operating case temperature:

  Standard: 0 to +70°C

  Applications

   10Gbps DWDM Optical systems  10GBASE-ZR at 10.3125Gbps  10GBASE-ZW at 9.953Gbps
   LTE systems

   Other Optical links


  Description

  The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 80km transmission distance with SMF.

  The transceiver consists of three sections: a Cooled EML laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

  The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.
