Advantages

1. Soft rubber can cushion the strength when falling.

2. Multi-color appearance can meet a variety of choices.

3. Aluminum alloy body surface uses sandblasting and anti-rust treatment, making it resistant to corrosion and ensuring a high life expectancy.

4. The four-column support structure has good impact resistance. It is sturdy and not easily deformed. It also features a rubber pad gap adjustment structure, making it easy to adjust and maintain.

5. The diameter of the shaft is thickened from 3mm to 4mm, doubling its strength.

6. The patented design ball groove impact self-returning positioning mechanism allows automatic reset after dropping and impacting.

7. High-elastic rubber fleece and double ruler 3-in-1 fixture help prevent fiber breakage.

8. The special composition rubber stainless steel pressure pads are resistant to oil, alcohol, and abrasion, ensuring high stability over long periods.

9. High-precision heat-treated stainless steel slides ensure smooth and fluid cutting.

10. The automatic return design enhances cutting efficiency.

Specification		Details
Material and Surface Treatment		Aluminum, Soft Rubber
Cutter Specification		Single-core quartz fiber, Inner bore Ø 4mm, External diameter Ø 22mm
Coated Diameter of Suitable Fiber		Ø 0.25 & 0.9, 125um
Clad Diameter of Suitable Fiber		Ø 0.25 & 0.9, 125um
Cleaving Fiber Length		9-16mm (Ø 0.25), 10-16mm (Ø 0.9)
External Appearance Size		60mm (W) × 57mm (D) × 46mm (H)
Weight		266g
Fiber Holder		3 in 1
Blade Hardness and Size		≥92.5HRa, 22 × 4 × 2mm
Cleaving Angle		≤0.8°
Blade Service Life		48000 times
Pressure Pad		Stainless Steel or Plastic
